Plasma Cutter CUT55 55Amp 110V Inverter DC Air HF Start Cutting Machine

Function：Plasma cutting







          Voltage（Frequency）：110V±15%（50/60Hz）

          Technology：IGBT&Inverter

          Cutting Thickness：14mm

          Cutting Width：1mm

          Input Current：10

          Cutting Current：10-55A

          Duty Cycle：60%

          Value of Current for Duty Cycle 100%：25A

          Air Afterflow Time：5

          Compressor Connection：0.4-0.6mpa

          Power Factor：0.93

          Efficiency Percentage：85%

          Surge Protection：YES

          Indulation Class：F

          Protection Class：IP21

This machine CUT55 is a newly upgraded plasma cutter, which can DIY cutting 14mm copper, steel, iron，aluminum and other metals. The design concept is: "reduce tedious operation steps and improve work efficiency". The clear operation panel and intuitive data display are convenient for users to operate and greatly improve the user experience. IGBT technology makes the body light and easy to carry. Inverter technology enables the persistence of machine work.



CUT：Plasma air cutting requires an air compressor to be connected. The optimum air pressure value is 0.4-0.6mpa. Different voltages, currents and air pressure values will affect the thickness of the metal that can be cut.

AFTER SALESSERVICEABOUT US

1 year warranty and 90 days free-of-charge return



Note: Partial refund or free replacement parts if products are damaged or missing parts due to logistics; Return or free replace according to the actual reason if products doesn't work.
