CUT65 Plasma Cutter Air HF Inverter Cutting Machine IGBT CUT 18mm Metal

• OUR STORE
• SELLER PROFILE
• FEEDBACK
• ABOUT US
• CONTACT

Function：Plasma cutting

Voltage（Frequency）：110±15%（50Hz）

Technology：IGBT&Inverter

Cutting Thickness：18mm

Cutting Width：1mm

Input Current：10

Cutting Current：10-60A

Duty Cycle：60%

Value of Current for Duty Cycle 100%：25A

Air Afterflow Time：5

Compressor Connection：0.4-0.6mpa

Power Factor：0.93

Efficiency Percentage：85%

Surge Protection：YES

Indulation Class：F

Protection Class：IP21

This machine CUT60 is a newly upgraded plasma cutter, which can DIY cutting 18mm copper, steel, iron，aluminum and other metals. The design concept is: "reduce tedious operation steps and improve work efficiency". The clear operation panel and intuitive data display are convenient for users to operate and greatly improve the user experience. IGBT technology makes the body light and easy to carry. Inverter technology enables the persistence of machine work.

CUT：Plasma air cutting requires an air compressor to be connected. The optimum air pressure value is 0.4-0.6mpa. Different voltages, currents and air pressure values will affect the thickness of the metal that can be cut.

1 year warranty and 90 days free-of-charge return

Note: Partial refund or free replacement parts if products are damaged or missing parts due to logistics; Return or free replace according to the actual reason if products doesn't work.
